The IBA-5 was primarily designed to be used from the inside of a building or structure. The main user of this product would be a CB'er who lives in an apartment or association area that restricts the use of outdoor antennas. Other uses may include single family residences, offices, and job-sites. The IBA-5 may also be useful to hunters and campers (on the ground or roof of your RV) to establish a temporary communications center. However, this antenna is not meant to be a replacement for an outdoor base station antenna. If you are allowed to set-up an outdoor base station antenna in your area you will probably benefit from doing so. In most cases the IBA-5 will not out-perform an externally mounted antenna so if you seek maximum performance and are allowed to use an external antenna, we recommend that you do so.
The complete assembly stands just over 5 feet (1.5m) tall. Assembly of the kit is fast and easy. Each kit includes a 'bare-hands tunable tip' antenna (rated at 1000 watts), a partially pre-assembled base hub assembly, four 30" (76cm) radials, and 18 feet (5.5m) of RG-58A/U Fire-Flex coax cable. We also include a couple of extra tuning screw that can be used in situations where SWR indicates insufficient ground plane. Complete assembly instructions are included.
The IBA-5 Indoor CB Antenna was introduced to the market in 1989. This product was an upgrade to the original antenna (IMB-5) that Firestik introduced in 1977.
The Firestik indoor antenna was designed for two basic reason: (1) to allow CB radio operation where outside antennas are not allowed or, (2) for the CB user who does not want to put up an outside antenna. In either case, the operator should be aware that this type of antenna is normally a compromise between rules, space and optimum performance. In most cases the performance will not match that of a good outdoor antenna. However, in many instances, the indoor antenna by virtue of its elevation, as well as the scattering effect the building has on its radiating field, has been known to out perform antennas of equal design on a vehicle at street level. Excellent performance can be recognized in spite of absorption by various building materials. DX'ing (long range communications) may not always be possible but is certainly a reality.
Indoor convenience is not without its limitations, and some compromise. An awareness of possible restraining conditions (e.g. building design, construction materials etc.) under which the antenna will be expected to perform can be appreciated more for an intuitive approach rather than an endless list of do's and do nots. With respect to indoor base antennas, the Firestik Indoor Base Antenna has gained a reputation for unexcelled performance. You should not let its limitations deter you from using it. When you are in a situation that limits your choices down to indoor antennas, be confident that the Firestik Indoor Base Antenna will satisfy or surpass most persons expectations of how it should work. Keep in mind that it was specifically designed to work indoors.
MECHANICAL DISCUSSION
The radiating element is a five-foot Firestik II type antenna with our patented tunable tip mechanism. The core is 3/8" fiberglass wound with 19ga double insulated magnet-wire. The antenna base is made of chrome plated 1/2" hex brass stock and has standard 3/8"-24 threads. The assembly is covered with white PVC shrink tubing.
The hub is a centrally located assembly that allows the antenna, coax and radials to be connected together. It is made up of two 2" circular metal disks, one upper and one lower. The upper disk has the coax and antenna coupling nut attached and the lower disk is used to connect the four ground plane radials. The disks are mounted directly above each other with 3/4" stand-offs.
The coaxial cable supplied with the kit is 18ft (5.5m) RG-58A/U. This is high quality, stranded center conductor coax with average shielding in the 95% plus range. A standard PL-259 connector is installed on one end of the coax for connection to the radio. The antenna end of the coax has our exclusive Fire-Ring connector for trouble free operation.
The ground plane for the IBA-5 is supplied by four (4) 1" (25mm) x 30" (76cm) flat steel radials. The radials are covered with black PVC shrink tubing and have a protective vinyl tip on the outbound end. At the hub end of the radial, a small hole is placed in order to secure the radials to the hub assembly.
LIMITATIONS
Unfortunately, indoor antennas will not, and can not be expected to radiate energy at high radio frequencies through all metal buildings. Buildings of all steel construction (top and sides), resting on earth or concrete slabs, can be expected to reflect virtually all incoming and outgoing transmitted energy without penetration. Buildings with steel siding resting on earth, but with wood frame roofs that are covered with wood shingles, composition or tar paper will allow radiation, but largely upwards. Some outwards radiation from the effects of scattering of the radio frequency field will depend on roof shape and height above the sheet metal siding.
Aluminum mobile homes will act like the steel buildings mentioned above. The difference, if any, will be in thin grade aluminum, where in addition to reflection, some absorption and re-radiation may occur, but direct penetration will be reduced.
Other limitations can occur in buildings where penetration and range is otherwise excellent under dry conditions. Reduction of radiated power will result from saturated wetting of the structures top and sides due to rainfall and heavy dampness. Under these conditions, limited range can be expected. Buildings constructed of concrete and steel, concrete block, cinder block or red brick will all appear earthy wet and will severely restrain radio transmissions. Otherwise dry, a large amount of scattering can be expected due to the combined effect of reduced penetration, absorption and re-radiation resulting in an unpredictable radiation pattern. Local horizontal distance may very well be restricted, yet, skip range expanded.
COMPROMISES
The five-foot antenna works as well as can be expected against the non-resonant radio ground plane comprising four 30-inch ground plane stabilizers. The ground plane stabilizers are made relatively short deliberately for ease of assembly and placement around any room, corner, furniture or even a closet or attic. The ground effect (apparent length) of the short radials is therefore affected by proximity to earth ground, electrical wiring or metal beams immediately beneath the aligned radials.
Concrete slabs represent good earth ground surfaces at CB band frequencies. The ground effect is diminished on wood frame ground level floors over high crawl spaces, and more so over basement areas. Ground effect is further diminished on wood flooring at second story levels and higher, except where as stated above, when placement happens to be in alignment immediately over electrical wiring or metal beams.
While an exterior mast mounted ground plane or dipole antenna is able to radiate into free space, the indoor antenna is surrounded by obstructions that tend to interfere with its ability to be tuned. An area should be chosen where it best works from the standpoint of SWR. When a spot is selected and the antenna is finally tuned in that spot, it should be left there. The area within 2 or 3 feet of the antenna should remain unchanged once it is tuned. Invasion of the near radiation field will de-tune the antenna unless it was specifically tuned with the obstruction at that point.
The performance and ability to tune the antenna will be best if the antenna can be located away from interfering objects. Undesirable conditions can be greatly reduced if near field objects are only on one side and at least 4 inches away from the antenna at the base, 8 inches away at one foot up, 12 inches away at two feet up and so on. The closer to the top of the antenna, the more critical is the proximity of other objects since the antenna design creates maximum radiation at the top loaded section.
Tuning the antenna for the lowest possible SWR is accomplished in the same manner as on a vehicle. Surroundings and ground plane area may not permit a SWR dip as low as that achievable on a vehicle or a resonant ground plane. Measurements reportedly have been as low as 1.2:1, however, 2.0:1 is by all means tolerable. At 2.0:1 SWR, the power loss is approximately 11%, which is less than 1/2 db.
TUNING AIDS WHERE DIFFICULTY IS ENCOUNTERED
The most common tuning problem with the IBA-5 shows up as high and relatively flat SWR. That is, even when finish tuning the antenna, the SWR at mid band (channel 19) is fairly high (1.7 to 2.5 range) and doesn't change much across the entire band. This condition is almost always caused by ground plane deficiency. In most cases this can be corrected by making the antenna electrically longer by changing the tuning screw on top of the antenna to a longer length (aside from the standard tuning screw, we supply an extra 2" and 3" screw in the package). If you have reached the upper maximum using the basic tuning screw, remove the vinyl cap and the tuning screw. Transfer the knurled lock nut and O-ring to the next longer screw and retune the antenna. The vinyl tip is optional, but remember if you tune the antenna with the tip off then put in on afterwards, the SWR will most likely change. If you want to use the tip and the longer screw, make an "x" cut in the top of the cap and run the screw through it.
Properly assembled and tuned on a ground level slab floor, the IBA-5 should show well under 1.5:1 SWR at the dip point (normally channel 20). On elevated floors where the SWR dip may remain insidiously high, indicating the antenna/ground plane network is quite reactive, the coax cable can become a part of the network and may contain standing waves, or a fractional part thereof. The coaxial reactance, or part thereof, may be eliminated by folding one to three feet of the coax back on itself in an S form. If a problem is still
Present, try a smaller or greater amount of cable in the double-back process, and do it in a different place along the cable itself until you find the combination which offers the lowest SWR. This technique may sometimes be improved by adding RG-58/U type coax to the existing length, totaling 24 feet from the mount center and increasing the double-back length.
If problems persist, set the whole assembly on a sheet or blanket. While an associate is keying up and advising on change of SWR readings, slide the entire assembly to another location. Stop at the location where SWR appears lowest and carefully revolve the blanket and IBA-5 assembly (no more than 1/4 turn) to detect any perceptible SWR improvement. Remove the blanket and fine-tune the antenna at its best location. Keep your distance from the antenna during the sliding around process.
ODDS AND ENDS
For those who like to scheme a little, a 16 to 118 foot length of wire or flat braid in a squared off Z form, obscured under a loose carpet, should work well to improve ground effect on upper level wood floors. Dress and tape opposing ends of wire to opposite corners of the room. Align one of the sets of radials directly over the center section of wire and fine tune the antenna in that location. If you use this method to increase your ground plane area then care should be taken if you are running high-powered radio equipment (linear amplifiers). High power directly relates to heat dissipation. If the wire cannot easily release heat generated by the power, the wires, in the additional ground plane, can become hot. The higher the power, the more heat! Keep that in mind.
Another process that can greatly increase the efficiency of the IBA-5, when set up in an attic, is the use of a spider-web ground plane. Using ordinary wire (coated or uncoated), create a web of wires running outward from the center hub. All ends at the hub assembly need to be connected to the bottom (ground) disc of the hub assembly.
OUTDOOR USE
Some of the mobile CB users also report excellent results from using the IBA-5 out of doors. It works great when placed upon the roof of a motorhome or travel trailer at your favorite camp site. Hunters have used it in their base camp to communicate with those using handheld or mobile radios while away from the camp in their CB equipped truck or ATV. The IBA-5 disassembles quickly for easy storage.
